- Model: WK6T
- Price: USD165
The default voltage for this series motor is 48V max torque 80nm, 220rpm, it is geared hub motor, reversible, with durable non-marking rubber tire, it is a brushless dc motor with hall sensors and it is ok to add encoder.
Also it is ok to make single shaft version, disc brake version and em braking version
The WK6T series has 6.5 inch and 8 inch tire diameter, the tire is high quality non-marking tire. This hub motor can be geared motor and gearless motor. For the geared version, the max torque can be 80N.m, 100N.m and 150N.m version. For the gearless motor, it also could be varies power.
8 inch high torque hub motor
6.5 inch high torque hub motor
| Model Number | WK6T65 | WK6T8 |
| Wheel size | 6.5 inch (170mm) | 8 inch(200mm) |
| Max torque at 48V | 80N.m, 100N.m, 150N.m | 80N.m, 100N.m, 150N.m |
| No load speed at 48V | 220RPM | 220RPM |
| Tire Material | durable non-marking rubber tire | durable non-marking rubber tire |
| Braking type | e braking | e braking |
| Gear type | Nylon gears, metal gears | Nylon gears, metal gears |
| Gear ratio | 1:5 | 1:5 |
| Sensor type | hall sensors, encoder | hall sensors, encoder |
| Others | disc brake, em brake, single shaft available | disc brake, em brake, single shaft available |
How much weight can the WK6T8 take?
hello. i like the 6.5in form factor but i will need a faster speed. do you have a model similar size with lower gear ratio? maybe 1:3. or can you modify this model?
it is ok to make this motor to be gearless version.
Does in lude esc controller?
Does support to move 2 persons?
Yes, it is ok.
