15X6-6 Garden Tire 100N.m 800W electric wheelbarrow motor

Home » hub motor » wheelbarrow motor » 15X6-6 Garden Tire 100N.m 800W electric wheelbarrow motor
  • Model: KK6156
  • Price: USD175

15 inch 48v 800w road geared hub motor for electric wheelbarrow, it is geared motor, reversible. It can be used for electric wheelbarrows, mobility, wheelchairs, agriculture tractors and so on. We also have the same power and speed dual shaft motor. Online buying link https://retail.uumotor.com/product/15-inch-fat-tire-100n-m-800w-electric-wheelbarrow-motor/

Motor: 15 inch fat tire 100N.m electric wheelbarrow motor(15X6-6 Carlisle Turf Saver Lawn & Garden Tire)
Hall sensor: YES (5 hall sensor wires)
Brake type: Disc brake or e braking
Motor rim size: 6 inch
Tire Model: 15×6-6 tubeless tire(360mm fat tire)
Max Torque: 100 N.M
Rated power : 600W(max 800w)
Rated voltage :24V36V/48V(default)
No-load current: <1.5A
pole pairs: 10
gear ratio: 5
Speed :10-12 km/h
Load Weight: 150-250kg
motor weight with tire : about 7kg

3 responses to “15X6-6 Garden Tire 100N.m 800W electric wheelbarrow motor”

  1. Trying to locate 4-5 inch concave wheel / roller for farming machinery project with 500-1000watt motor
