- Model: H8166502
- Price: USD358
48V 2000W (peak 3000w) brushless dc geared hub motor, rated speed 150RPM, max torque 400N.m.
High torque, low speed, steel gears, more strong, and more durable, reversiable, regen braking, encoder availble.
Packing weight: 17kg.
Pole pairs: 10
Tire size:16×6.5-8 tubless off road tire.Max load 800kg.
It is ok to run at 72V to get more power and torque, speed will increased to 270RM.
The shaft is a completed new design splined shaft and increased the shaft diameter to M18,fat-14mm, there will be no any of key broken problem. It is with strong steel gears, reversible, No load current is about 2.2A. It is a standard geared brushlesss hub motor, which has hall sensors, and it is ok to add temperturer sensors and encoder. It is also ok to add encoder, and we can install 17 inch and 18 inch tire on this motor too.
