- Model: HH35
- Price: USD65
3.5 inch(93mm) 24V 180w brushless hub motor, max load 100kg, max speed 10km/h,motor weight 0.95kg. It is ok for child electric scooter hub motor,electric luggage or other small electric vehicles.
Motor Specifications
| Motor Diameter | 93 mm |
|---|---|
| Rated Voltage | 24 VDC |
| Rated Power | 180 W |
| Rated Speed | 650 ± 50 RPM |
| Rated Current | 5 ± 0.5 A |
| Maximum Torque | 4.5 N·m |
| Hall Sensor Phase Angle | 120° |
| Number of Pole Pairs | 10 |
| Shaft Type | Dual-Sided Internal Threaded Shaft |
| Cable Length | 600 mm |
| Braking Method | Electronic Brake |
| Shaft Material | 45Cr Steel |
| Protection Class | IP55 |
| Maximum Load Capacity | 100 kg |
| Operating Temperature | -20°C to +65°C |
Hello,
is it possible to customize this motor ?
I need 36 V 150W and low KV.
Needed for wheelchair assist funktion with 2 motors.
Thank you.
Can you deliver to Ireland
Yes. We can ship it via air express by Fedex, UPS or DHL.
