48v 500w slow speed 13 inch geared hub motor

Home » hub motor » wheelbarrow motor » 48v 500w slow speed 13 inch geared hub motor

Category:

Tags:

,
  • Model: M2PH-L
  • Price: USD135

13 inch 48v 500w powerful high torque geared hub motor for electric wheelbarrow trolley and hand truck. Rated speed is about 7-10km/h. it can be also other speed as per your request.

Motor: 13 inch Brushless Geared Motor or other tire size
Hall sensor: YES (5 hall sensor wires)
Brake type: Disc brake, e braking
Tire Model: 13×5-6 Vacuum tire
Max Torque: 59 N.M
Rated power : 500W
Rated voltage ：36V 48V
No-load current: <1.5A
Speed : 7-10km/h
Load Weight: 100kg-150kg
Dropout size : 135-145 mm
Weight : about 6kg

12 inch wheelbarrow motor drawing
48v 500w geared wheelbarrow motor testing data

8 responses to “48v 500w slow speed 13 inch geared hub motor”

  1. Can you tell me what the gear ratio is for this motor? What would be the approximate shipping cost to Pennsylvania, US? Thank you

    Reply
