- Model: KM5D(HB5GL)
- Price: USD155
- 48v max 50N.m torque
- pole pairs: 10
5 inch geared high torque hub motor, smaller but powerful, reversible, with hall sensors, gear ratio 1:6.5 , we also have a 4 inch version of this motor, the same motor,samller tire size.
This smaller hub motor only 5 inch with tyre. It is durable non-marking solid rubble tire. Please noted this is a pwoerful small motor, the power is bigger than a gearless small motor. Its peack torque can reach 50N.m.
The mini go kart powered by our 5 inch motor:
what is the efficiency of this motor?
80%
Hi, is this motor still available?
Is there a known joystick system that can control two of these like in a wheelchair?
Thank you
Dimitre
Yes. It is available. Our wheelchair joystick controller can drive it.
Hello! What is the name of the provider?
we are the provider. you could buy it directly from our online store
Are there any options for higher torque on these motors, and if so, what torque options are there? or are there any other products in the 4-6 inch range that have higher torque? I am looking to buy several of these motors for a student project
Thank you!
we will soon have a new 4 inch geared motor with higher torque.
What is the stator size? Diameter and length.
Sorry, we will not reveal the stator details here in the post.
Hi Tony,
I am making a wheelchair for myself. Can this motor be customized for 250w at 24v, with maximum speed of 10kmph? Also, do you have instructions for changing the tire?
24v version, speed is about 15km/h, and to change tires, you need to open one side motor cover.
I’m interested in the 48v version of this motor but when I followed the link to it there are only the options for the 24v and 36v versions. Does you’d mean that the 36v motor will run at 48v or is there something km missing. Thanks.
Hello Ben,
We can customize the 48v version for you, how many pcs of this 5 inch motor do you need?
How high is the torque of the 5 inch motor?
The max torque is 3.8N.m
Can you please send me the technical information on this hub motor, please?. Thanks
Hi, I’m looking at buy several of the 5″ hub motors but need a low rpm, around 210-330 @ 24V.
What is the lowest RPM you could do at 24V?
Thanks,
Oliver
Our lowest speed is 10km/h.
hi,
is it hall sensored?
Yes, it is sensored.
What is the maximum load for This motor?
80KG
What is the weight of the 24v, 36v and 48v versions of this hub motor please?
The motor weight is about 1.9kg.
serian tan amables de darme el precio por el kit completo del scotter las llanta tracera de motor y frenado y llanta normal mas su controlador y baterias y cargador de las mismas que sea de 48volts a350watt,s gracias
tienen de 500watt a 24v espero respuesta para adquirir pais de mexico
deseo que me informen de datos tecnico de bercion scotter llanta 5 pulgadas frenado de regeneracion o tracero su precio para mandar al pais de mexico
espero su informacion gracias estare pendiente
Are u in china? How can I buy it? Please email me.
you can email us at sales@uumotor.com for buying.
Is this 5 inch version available for sale now?
Yes, it is ok to sale now. How much do you need?
Price does it carry 80kg at least one people
Usually, it carries 75kg. 80kg is ok.
is this a sensorless version? Does it also supports a regen braking?
