- Model: HTS10
- Price: USD150
24v-48V 350W-500w, max 40RPM, max torque 200N.m, it is a hall sensors motor, reversible. 10 inch solid tire, 1:22 gear ratio
- Ultra-low speed
- High torque output
- High reduction ratio (planetary geared 22:1 and 25:1 optional)
- Position feedback via Hall sensors (not servo precision)
- Suitable for heavy-duty, slow-moving vehicles
- 10 inch solid rubber tyre (250X150)
Product Overview: High-torque 10-inch brushless geared hub motor engineered with a high reduction gear ratio (22:1 standard, customizable up to 25:1) and a durable solid rubber tire. Rated at 500W low power consumption, this compact wheel motor delivers exceptional payload capacity, low-speed efficiency, and zero-maintenance operation for AGVs, electric wheelbarrows, utility carts, and industrial automation equipment.
High-Torque 10 Inch Brushless Geared Hub Motor with Solid Rubber Tire (500W)
Engineered for heavy-duty, low-speed industrial transport, this 10-inch brushless geared hub motor combines a high planetary gear reduction system (22:1 standard, customizable to 25:1) with a low-power 500W BLDC motor. By leveraging extreme gear reduction, it maximizes output torque while operating efficiently at low power levels, making it the ideal drive solution for heavy loads, steep inclines, and continuous low-speed operations.
Equipped with a puncture-proof solid rubber tire, this motor eliminates flat tires, air pressure maintenance, and downtime, ensuring 24/7 reliability in aggressive factory, warehouse, construction, and agricultural environments.
Key Features & Performance Advantages
- Extreme Gear Reduction Ratio (22:1 / 25:1 Custom): Built-in planetary gearbox achieves a high reduction ratio (22:1 standard, 25:1 optional), allowing the 500W BLDC motor to deliver massive low-speed wheel torque without overheating.
- Energy-Efficient 500W Rated Power: Provides high payload pushing capacity while consuming minimal battery power, extending vehicle operation cycles per charge.
- Puncture-Proof 10 Inch Solid Tire: Heavy-duty, maintenance-free solid rubber tire ideal for rough terrain, construction sites, and sharp industrial debris.
- Reliable Brushless DC (BLDC) Technology: Hall sensor integration ensures smooth start-up performance under full load, precise low-speed control, and long-term durability.
- Reversible & Compact Integration: Supports forward and reverse direction controls with direct-drive hub integration, saving chassis design space.
Technical Specifications
| Specification | Details |
|---|---|
| Motor Type | Brushless Geared Hub Motor (BLDC) |
| Wheel Size | 10 Inch |
| Tire Type | Puncture-Proof Solid Rubber Tire |
| Rated Power | 350W,500W |
| Reduction Ratio | 22:1 (Standard) / 25:1 (Customizable) |
| Position Sensing | Hall Sensor Integrated |
| Rotation Direction | Reversible (Forward & Reverse) |
| Primary Characteristics | High Torque Output, Ultra-Low Speed, Low Energy Consumption |
Typical Applications
Thanks to its ultra-high gear reduction ratio and heavy-duty solid wheel design, this 500W geared hub motor is optimized for low-speed, high-load machinery, including:
- Industrial AGVs & AMRs: Automated Guided Vehicles, warehouse logistics robots, and heavy payload transport platforms.
- Electric Wheelbarrows & Carts: Construction mini dumpers, powered hand trucks, orchard and greenhouse utility carts.
- Specialty Mobility Equipment: Heavy-duty electric wheelchairs, campus service vehicles, and airport baggage handlers.
- Outdoor & Farm Equipment: Agricultural transport modules, robotic field platforms, and equipment towing systems.
Customization & OEM Solutions
We provide OEM/ODM customization services for global machinery manufacturers and system integrators. Customized gear ratios (such as 25:1), specific voltage configurations (24V/36V/48V), axle designs, and matching motor controllers are available upon request to meet your exact technical requirements.
