- Model: MI250
- Price: USD135
For the replacement of xiaomi mijia electric scooter, The motor power 36v 350w, peak power 500w, max speed is about 40km/h, rated speed is about 30-35km/h. max torque 16N.m. 81/2-2 tire air tire.xiaomi m365 motor replacement is available again. You can buy it directly from our online store here https://www.uumotor.com/ws/p/8-5-inch-xiaomi-m365-electric-scooter-front-drive-motor-replacement/
Category
Tags
4 inch hub motor 5 inch hub motor 6 inch hub motor 8 inch hub motor 8.5 inch motor 10 inch hub motor 12 inch hub motor 13 inch hub motor 14 inch hub motor 15 inch hub motor 16 inch electric bike conversion kit 16 inch hub motor 20 inch hub motor 90mm hub motor 250W electric bike conversion kit 250w motor 350w motor 500W electric bike conversion kit 500w motor 800w motor 1000W electric bike conversion kit 1000w motor 3000w scooter motor 3500w hub motor disc brake motor disc braking motor drum brake hub motor e bike motor electric motorcycle motor electric scooter motor electric scooter motor kit electric trike kit electric wheelbarrow motor electric wheelchair motor Geared motor high speed motor hub motor with encoder in wheel hub motor low speed high torque motor mono shaft motor pneumatic hub motor pu tire motor servo hub motor single shaft hub motor wheelchair motor kit
53 responses to “35km/h 8.5 inch xiaomi mijia electric scooter motor replacement”
Do you offer a lower speed but higher torque alternative for m365?
No. we do not have that.
Is there any alternative? I saw on Amazone the same tire/motor with 500W but but i cant order it to germany…. what a pitty! So can you tell me when it is back in stock? Or just another site where they have this motor with 500watts and they will send to germany? I would really appreciate that!!! Thank y’all and happy new Year ?
Hello! I’m interested in this motor. Can you send me the datasheet document by email. Do you have the same motor of higher power?
Es un timo, no es el motor el que hace alcanzar 40 km/h sino la batería… espero que nadie caiga en este timo.
Bonjour. donc ce moteur à un KV plus élevé que celui d’origine ? donc moins de pôles ?
hi . So this motor have a higher KV than xiaomi original one ? so less magnetic poles ?
Yes.
Hi
Do you have this motor available for ebikes
Rafe
Does this motor reach 40 km/h on stock firmware or is flashing custom firmware required?
the motor speed is 40km/h, but your controller may be not ok to provide with enough current.
So do you have controller wich can do that with this 40km/h motor
Not yet.
Hi, with the new more powerful motor – will this mean that the scooter will climb hills without having to kick push with my foot. At the moment the scooter struggles to run continuously up hills that around 15 to 20 degrees or more. I weigh 60kg’s, and really want the scooter to seamlessly carry me up hills that aren’t too steep. Look forward to hearing from you.
no. th fast speed means torque may be lower than before.
Is this really a faster motor?
As in all I replace is this motor on my m365 and it will now do 40 kmph real world with no additional charges?
No firmware changes or battery changes no change to BMS nothing but this motor and my xaoimi will now do 40kmph ?
I feel like this is the same motor, as I’m sure the original motor is rated to go 40kmph if I gave it more power (modified the bms)
Please let me know for sure if this will make my m365 do 40kmph I’ll buy it straight away.
Also is 40kmph the MAXIMUM this motor could ever go?
What if I doubled my batteries and set them up in parallel to put out up to twice the power?
I really want to do everything possible to increase speed and range of my m365 my goal is to get it to 50kmph and increase the acceleration / torque
Thanks
the motor is real fast and the original controller may be not ok to provide big current for the motor and some times, the original controller may shut down the motor power dutu the over heating of controller.
Hi
Do you have this motor available for ebikes
Rafe
So if I install this motor to xiaomi m365 electric scooter, it will go faster than with the old motor?
yes.
The description is the same as the original but it is written 40 km / h.
Then how can I go faster with this than with the original?
the motor is designed to be a fast motor.
Where can i buy this?
you can buy it here directly https://www.uumotor.com/ws/p/8-5-inch-xiaomi-m365-electric-scooter-front-drive-motor-replacement/
What is the fastest motor you have that will fit into a xiaomi mi 356?
the fast motor we have now is 40km/h.
is there anyway that this hub can spin/ operate with out useing a speed controler. basically with a switch where its either on or off. if so can you explain . thanks
it usually can not, the controller has protection for such operation.
Hi, I have stupidly snapped some of the wires to the motor while changing the tire, is there any way to fix the wires or could I just buy a new motor and will that solve the issue? Thanks in advance. Looking forward to hearing your advice.
You can open the motor and soldering the wires.
Thank you for your reply, I have tried this option although the wires are broken too close to the middle shaft. I have decided on replacing the motor. But the main problem I have is, If I buy the motor online, I have no idea how to hook up the new motor once it arrives. Is there any tutorial or instructions anywhere on the internet or an easy explanation for a simple woman like me?
it is not easy, out motor is not original xiaomi motor. You need to change controller wires method to let the controller and motor marched well.
How can I access the controls inside the front tube? Can the tube be disassembled? How can I disconnect the old cables and connect the cables of the new motor?
thanks best regards
Sergio.
can you please provide exact measurements for the hub motor (not only the tire ) i need end axel , end hub and all the info
thanks best regards
Alex
How do you install the new motor. I burnt my motor out so have ordered a new motor but not sure where the wires are to plus in / connect. Cheers
all wires are in the front wheel and tube.
find the controller in the front bike tube and you will know that.
Hey,
I try to put a new tube on the front tyre
but the air pump thingy wont go in the hole, cause its too tight.
i saw that there is a small plastic thingy that controls the movement of the air pump, so i tried to reach it..
I tried opening the cover of the motor with tx20 – i removed all the screws but it still wont open,
how can i open it?
Thanks!
the air pump valve is really hard to remove, no good ways. open the cover does not help to make the air pump out. You could change the tire to hollow tire(no air tube)
I have the same problem with the valve just today! I got a flat and I can not pull the valve out of the hole. I bought solid tires now, just waiting it to arrive. I will saw the current valve to make it shorter and remove it
Hello,
Can you repair my old motor?
we can, but the shipping cost is expensive.
Can u provide kit with drive and non drive wheels, with controller, and disc brake on one or both wheels
Yes, we can. please email sales@uumotor.com for the buying details.
My cousin gave me his old Xiaomi m365 e scooter,the problem is,the circuit board is broken and I cannot start it without it.besides buying one new,can I just put a off on switch on it instead?.
you can replace it with a normal electric scooter controller to let the scooter run again.
Hi how does this motor stop the tyres breaking?
It needs the controller to braking the motor.
I see will this motor heat up. My original motor gets really hot.
every motor will heat up if it is overloaded. This motor 90kg is ok, not heat up quick. And if also the motor wires broken also can make the motor heat.
When the motor heats up the tyres pop because the air expands too much.
Hello tony how are you ? My main concern is the speed or power of my Xiaomi m365 , I’m 220 lbs every time I ride my scooter a little bit uphill it run very very slow sometimes I just push the scooter & walked with it is there any solution to make my scooter faster r at least a little additional peer , pls text me if you don’t mind my text number is (626)316-8053 my name is oscar I really appreciate if you do thsnks? Or email me
Thanks waiting for your reply
