- Model: TG6T
- Price: USD135
You could buy this motor TG6T via paypal from our online store https://www.uumotor.com/store/26-6-inch-small-hub-motor-250w-20kmh.html
[su_slider source=”media: 1418,1423,1422,1421,1420,1419″]
6 inch gearless brushless dc motor, dropout size 65mm, can assemble band braking or disc braking as per specific application, reversable, regenerative braking.
voltage:24V/36V/48V
power: 150～250W
speed: 540～1400rpm (15KM~30KM)
efficiency: ≥83％
wheel diameter: 6″（150mm）
net weight: ≤2.0kg
dropout size: 65mm
noise: ＜60dB
waterproof grade: IP54
brake: band brake, disc brake, e braking
Category
Tags
4 inch hub motor 5 inch hub motor 6 inch hub motor 8 inch hub motor 8.5 inch motor 10 inch hub motor 12 inch hub motor 13 inch hub motor 14 inch hub motor 15 inch hub motor 16 inch electric bike conversion kit 16 inch hub motor 20 inch hub motor 90mm hub motor 250W electric bike conversion kit 250w motor 350w motor 500W electric bike conversion kit 500w motor 800w motor 1000W electric bike conversion kit 1000w motor 3000w scooter motor 3500w hub motor disc brake motor disc braking motor drum brake hub motor e bike motor electric motorcycle motor electric scooter motor electric scooter motor kit electric trike kit electric wheelbarrow motor electric wheelchair motor Geared motor high speed motor hub motor with encoder in wheel hub motor low speed high torque motor mono shaft motor pneumatic hub motor pu tire motor servo hub motor single shaft hub motor wheelchair motor kit
12 responses to “dropout size 65mm hollow tire 6 inch gearless hub motor”
Do you have ay 6 inch / 6.5 inch 36v motor that could go faster than this : around 40 km/h 45 km/h it could be rated 500w or more ? thanks in advance.
Hello,
Could I possible have better images of the side mounts of the wheel?
Thank you.
Yes, please email us at sales@uumotor.com for the motor details.
How can I change the tire? After removing the six screws on each side, the cover plate releases a little and turns freely on the side with the wires, but I cannot remove it further. Suggestions? How to open the motor?
you need to remove one side cover. I will email you from sales@uumotor.com
[…] kit includes the following parts: 1. 8 inch gearless hub motor with solid tire,dropout size 65mm. 2. regen braking controller 3. twist/thumb throttle with battery indicator 4. […]
[…] For the motor details, please refer to here https://www.uumotor.com/dropout-size-65mm-hollow-tire-6-inch-gearless-hub-motor.html […]
Another question.
Are the motors reversible?
Thanks
Yes, it is reversible. All gearless motors can run reversibly.
Hello ,
I have a doubt, I have a wheel chair controller for a brushless motor,
is there a way to know if it will work with your motor?
Our motor phase angle is 120 degree. Usually your controller should be ok to work with our motor.
[…] Suitable for light weight electrical scooters. We also have this motor in dropout size 65mm version. […]
